| CPU Socket Type |
AMD AM5 |
| CPU Type |
AMD Ryzen 7000 Series Processors |
| Supported CPU Technologies |
Raphael AM5 |
| Chipset |
AMD X670 |
| Number of Memory Slots |
4x DIMM |
| Memory Standard |
DDR5 support up to 6600(OC) MHz |
| Maximum Memory Supported |
128 GB |
| Expansion Slot |
3x PCIe 4.0 x16 slot(Supports x16/x4/x2), 1x PCIe 3.0 x1 slot |
| Storage Devices |
1x M.2 Gen5 x4 slot, 3x M.2 Gen4 x4 slot, 6x SATA III port |
| Onboard Video Chipset |
Integrated Graphic on Processors |
| Onboard Audio Chipset |
Realtek ALC4080 Codec |
| Audio Channels |
7.1 Channel HD Audio with Audio Boost 5 |
| Onboard LAN Chipset |
Realtek RTL8125BG, Wi-Fi 6E, Bluetooth 5.2 |
| Onboard LAN Speed |
2.5G LAN, WiFi 6E, Bluetooth 5.2 |
| Real Panel Ports |
1x HDMI, 1x DisplayPort, 1x USB-C3.2 gen2 (Alt DP), 1x USB-C3.2 gen2x2, 2.5Gb LAN, WiFi connector, HD Audio jack |
| Onboard USB |
1x USB-C3.2 gen2 port, 4x USB3.2 gen2 port, 4x USB2.0 port |
| Dimensions W x D x H |
30.5 x 24.4 cm |
| Case spec |
ATX Form Factor |
| Power Pin |
1x 24-pin Main Connector, 2x 8-pin Power Connector |
| Warranty |
3 Year |
